Features
1. The electric suction device consists of a negative pressure pump, a negative pressure regulator, a negative pressure indicator, a collection container assembly, a foot switch, and a chassis
composition;
2. It can meet the requirements of various hospitals and medical units that require high efficiency and large flow attraction during medical operations.
The treatment unit is used for surgery to attract pus and blood and various mucous secretions;
3. Vertical structure, novel design, beautiful appearance;
4. Double-head piston vacuum pump is used as the suction source of negative pressure, with low noise;
5. Equipped with anti-overflow safety device, maintenance work is simple, no need to refuel;
6. The manual and foot switch can be used in parallel, and the operation is convenient;
7. According to the type and degree of protection against electric shock, the electric suction device is classified as the application part of type I equipment and type B, and the operation mode is intermittent.
Load continuous operation (intermittent suction), IPX0, non-AP type or APG type ordinary equipment;
8. The product meets the relevant requirements of GB9706.1. YY0505 and YY0636.1.
Technical index
1. Negative pressure limit value: ≥0.09MPa (680mmHg);
2. Negative pressure adjustment range: 0.02~0.09MPa (150~680mmHg);
3. Pumping rate: pump port (air outlet) ≥35L/min, terminal ≥25L/min;
4. Power supply: AC220V ± 22V, 50Hz ± 1Hz;
5. Power: ≤280VA;
6. Noise: <60dB;
7.Capacity of collection container: 2500mlX2;
8. Working environment: temperature +5°C~+35°C, relative humidity: 25°C no more than 80%, atmospheric pressure: 86KPa~106KPa.
