MDTHYQ1_0924
MDT
MDTHYQ1_0924
Features· MonophaiscTechnical specifications DEFIBRILLATOR.(1) Defibrillator type Manual,synchronized,asynchronized (2) Energy accuracy ∠+1%(3) Energy selection 0, 20, 50, 100, 160, 250, 300, 360 joules (nominal at a resistance of 50)(4) Charging time Maximum 10 seconds to 360 Joules(5) Standard Adult/Pediatric Paddles Reusable external adult paddles(pediatric paddles integrated) Power requirements (a) AC Power supply 100V~240V,50Hz/60 Hz (b) Vehicle Voltage(Option) DC 12VInternal Battery Backup(1)Battery type Rechargeable lead-acid battery (12V 2.0Ah X2)(2)Charging time Time-Minimum of 4 hours for full charging (3)Battery charging During AC Power Supply operation of the device.(4)Charging /Low Battery Indication Red LED (5)Battery Capacity 100% of the battery will provide 120-min of monitoring; and 35 discharges at 360 joules.
Display-LCD Dimensions 10.4 inch-Type High resolution true-color graphic LCDECGECG lead: Ⅰ, Ⅱ, Ⅲ, AVR, AVL, AVF, V1~V6
S-T segment analysis: -2.0~2.0mv
Arrhythmia analysis: yes
Protection: With stand 4000vAc/50Hz voltage in isolation and work against electrosurgical knife and defibrillation
RespirationMeasurement method: Thoracic impedance
NIBPWorking mode: Manual/Automatic/stat
Method: Automatic oscillation
Cuff type: standard Adult; optional Pediatric/Neonatal
TemperatureMeasurement range 20~45℃Resolution 0.1℃
Pulse Oximetry(spO2)Display :spo2 value, pulse histogram, waveform, PulseRange: 0~99%for adult, pediatric and neonatal patientsProbe :standard adult finger clipoptional pediatric Y-type clip and neonatal wrap
Pulse range
Pulse range: 0-255bpm
Standard parameter & configurationECG/ RESP/SPO2/TEMP/PR/NIBP/DEFIBRILLATOROptional parameterRecorder, Li-ion battery (11.1V 4Ah X2)
