Item: VP10 3.5"touch screen
Name: Infusion Pump for Human or Vet.
Item: VP10 3.5"touch screen
Size: L165 × W103 × L100mm. Weight: 1.3kg.
Power: 100~240V, External DC Power: 10V~16V
Battery: 2600mAh, working 8 hours above in 25ml/h speed.
Double CPU. IP34warterproof / dustproof/shockproof.
Flow Rate range: 0.1~1200.00ml/h, increment 0.01ml/h.
VTBI: 0.0-9999.99ml, Time: 1s-99h59min.
KVO: 0.1~5.0ml/h, increment 0.1ml/h.
Accuracy: ±5% (use the IV set calibrated)
Purge: 0.1-1200ml/h. IV sets: Dia3-5mm or setting
Bolus rate: 0.1~1200ml/h, Automatic/Manual bolus available
Bubble size: Adjustable 50/100/250/500/800 μl. Ultrasonic detection.
Occlusion pressure detection: Adjustable Low /Medium /High.
History Record: 2000 above. Night mode: setting and adjustable.
Temperature:-22ºC-55ºC,Relative humidity:10%-95%,
Atmospheric pressure: 40~120Kpa.
Alarm: Air Bubble, occlusion, infusion finished, standby time end,
low VTBI, low & empty battery, AC/battery disengaged, motor /
pump /pressure sensor/ parameter error, system abnormal.
