| Quantity: | |
|---|---|
MDTWJ_0072
MDTPA189537YT71542
MDTWJ_0072
specifications and models | YTLED700 | YTLED500 | YTLED400 |
Shance (adjustable) Lux | 40000-180000lux | 40000-160000Lux | 40000-80000lux |
The number of bulbs | 80 Of | 48 Of | 30 of |
Average light bulb life span | ≥80，000h | ≥80，000h | ≥80，000h |
Color temperature (adjustable) | 3500K ～5000K | 3500K ～5000K | 4500K±500K |
Display index (adjustable) | 85～98 | 85～98 | 90 |
depth of focus | ≥1200mm | ≥1200mm | ≥1000mm |
working radius (mm) | 600-1800 | 600-1800 | 600-1800 |
spot diameter | 160-280mm (adjustable) | 160-280mm (adjustable) | 160-280mm (adjustable) |
brightness control | 1%-100% | 1%-100% | 1%-100% |
irradiance | 6w/m² | 6w/m² | 6w/m² |
UV irradiance | 0.3w/m² | 0.3w/m² | 0.3w/m² |
supply voltage | AC100-240V 50/60HZ | AC100-240V 50/60HZ | AC100-240V 50/60HZ |
interiorinput power | 200VA | 200VA | 200VA |
Optimal mounting height (mm) | 2600-3000 | 2600-3000 | 2600-3000 |
Product features:
1. Real cold light source
★ The use of new LED cold light source, energy saving, environmental protection and ultra-long service life up to more than 80,000 hours. It is 40 times longer than the halogen lamp life. At the same brightness, LED energy consumption is only 1 / 10 of ordinary incandescent lamp and 1 / 2 of halogen lamp.
★ LED does not produce infrared and ultraviolet radiation, halogen less lamp temperature rise and tissue damage caused to the wound, reduce radiation pollution.
★ LED color temperature is constant, color temperature color does not attenuation, soft not dazzling, very close to the natural solar light, no ultraviolet radiation, no strobe.
2. Excellent shadowless effect
★ The lamp head adopts the most scientific radian, built-in eight sections, mold, multi-point light source design, light spot adjustment is flexible, so that the light spot illumination is more uniform, when the surgical lamp is partially blocked, it can also achieve the perfect shadowless effect.
★ Use two lamp beads of similar color temperature to avoid the vertigo of the surgeon.
3. Excellent depth lighting
★ Using computer-aided modular design, multiple LED light columns focus irradiation, produces deep illumination of more than 1200 mm, the center illumination up to 180000l u x, and provides 3500K-5000K adjustable color temperature close to natural sunlight, truly reflect the color of human tissue, fully meet the needs of all kinds of surgical lighting.
★ With endoscopic surgery mode, soft ambient lighting; press the ambient lighting button to indicate only the endoscope ambient lighting, leaving only 8 LED of the road for lighting, and close the remaining LED light emitting diode string; press this button again, you can return to the original illumination display state. It plays a very good auxiliary role for the local depth lighting.
4. Advanced control system
★ Using LCD display push-button control, power switch, illumination, color temperature adjustment, to meet the requirements of medical staff for different patients surgery brightness.
★ Digital memory function, automatic memory suitable lighting degree, open again without debugging.
★ Multiple groups of the same power centralized control methods to ensure that single channel single LED damage does not affect the surgical lighting requirements.
5. Multi-direction suspension system
★ Rotating arm, 50 * 70 standard rectangular tube shape is safer and more beautiful; the carbon brush access mouth of rotating arm adopts ABS mold molding, no leakage screw fixed, more harmonious and beautiful.
The balance system uses high quality spring arm components, light structure, easy to control, accurate positioning, can provide the maximum adjustment range.
6. Modern laminar flow lamp head
★ Round ultra-thin design, the thickest part is not more than 10CM, for excellent laminar effect.
The lampshade case is made of aluminum, and the handle in the lamp head can be removed for easy adjustment and flexible positioning.
