MDTWJ_0058
MDTZC53188983898
MDTWJ_0058
MRT-01 Medical Needle Tubing Stiffness Tester
Suitable for the determination of the stiffness value of the rigid straight stainless steel needle tube for human intradermal, subcutaneous, intramuscular and intravenous disposable injection needles, prefilled syringe needles, etc.
Technical Features
-7-inch color touch screen with intelligent data processing functions providing users with a comfortable and smooth operating experience
-Equipped with advanced displacement control system to ensure test accuracy
-Concise and intuitive operation interface, convenient user-defined test functions, and complete data analysis and reporting functions
-Automatic calibration, simple and convenient operation
-Brand-new UI interface design, intuitive operation interface, greatly improving the operation experience
-Automatic judgement of test status and result qualification.
-Support a variety of specifications sample test, normal wall, thin wall, ultra-thin wall can freely choose
-With automatic data storage, power-off automatic memory function
-Micro printer and USB data interface, convenient for data output and transmission
-Powerful data storage function, which can store more than 6000 data
-The computer software fully complies with the requirements of GMP "Computerized System", with functions such as user management, authority management, and data audit trail.
Test Principle
The instrument applies prescribed bending force to the injection needle sample, and the special sensor of the rigidity tester measures and records the rigidity of the needle tube at the point of application.
Applications
Basic Applications | Disposable sterile injection needle | Used to determine the deflection value of disposable needle tubes for human intradermal, subcutaneous, muscle and intravenous injection needles and rigid straight stainless steel needle tubes for other medical devices; |
Prefilled injection needle | Rigidity test of stainless steel injection needles for prefilled syringes required by pharmaceutical packaging material standards | |
Extended Applications | Infusion needle | Used to detect the rigidity value of the infusion needle tube |
Needle tube | Determination of rigidity values such as stainless steel needles, blood sampling needles, dental needles and biopsy needles |
Technical Specifications
Specifications | MRT-01 |
Deflection Range | 0-5mm |
Deflection Accuracy | ±0.01mm |
Bending Force | 1-80N |
Force Accuracy | ±0.01N |
Needle Span | 0-60mm |
Span Accuracy | 0.1mm |
Needle Tube Specifications | 0.3mm-3.4mm (Regular wall, thin wall, ultra thin wall) |
Loading Speed | 0-10mm/min (Stepless speed) |
Speed Accuracy | ±0.1mm/min |
Instrument Dimension | 300mm (L) x 300mm (W) x 400mm(H) |
Net Weight | 23Kg |
Power Supply | 220V/50Hz |
Standards
ISO 9626, GB 15811, YBB00092004-2015, GB 18457
Configuration
Standard configuration: Instrument, micro printer, touch screen, test fixture.
